Cutting Materials of cnc wire rigid foam cutting machine:
Hard thickness foam, such as hard EVA with 140 100 80 density, polyurethane PU foam, 90 density rigid pu foam, Mineral wool/Rockwool with different density, such as 120 density, 160 density, 240 density etc., Corafoam for insulation pipe, fiberglass etc.

Cnc wire cutting machine Parameters:

Features of horizontal polyurethane foam cutting machine:

1.machine main body use rectangular steel pipe and many kinds of connectors. This cnc wire cutting machine is made with reasonable structure, stable performance, high precision, easy operation. Can save time, save labor cost, save raw material.

2. Through control X axis and Y axis Run synchronously to work, and at same time use cutting wire to cut many different kinds of insulation material and other material. For example: EVA, PU foam, sponge, homogeneous plate, silica sheet, rock  wool, glass wool, mineral wool, foamed cement, foamed glass, foamed ceramics, Polyurethane foam, Real gold board, polystyrene board, cardboard, honeycomb corrugated paper, gypsum board, PE etc.

CNC wire eva pu foam cnc cutting machine Use the graphics input into the computer to automatically send out pulse signals to control the operation of the X and Y axes，is Suitable for cutting products with large volume or small quantity，The machine uses a stepper motor with smooth movement and free speed adjustment, which is suitable for cutting typesetting of special graphics and requirements for continuous speed change.

3. Gantry is with Humanized treatment, when machine working, cutting wire is embed into gantry to protect operator, high safety.

4. The cnc wire foam cutting machine adopts an advanced computer control system, and the graphics software can be used directly on the computer to draw the required graphics, edit the cutting path layout, and save the code. Load the G code into the cutting software for efficient and stable cutting. You can also use a USB flash drive to input the G code file of cutting pattern or text into controller. The operation is simple and easy to understand.

4. Computer screen can show cutting design. Can set different cutting speed according to different material. Max rapid traveling speed can reach 5000mm/min. we will set all parameters before delivery.

5. This cnc wire sponge foam cutting machine is equipped with alarm device, if cutting wire is broken, it will alarm. This machine can do cutting, inverse cutting, mirror symmetry, Backlash compensation etc.

6、Can use cad software to make design, save it into dxf or cnc format file, then import into mach3 controller. Easy operation.
